DVIA-MB1000 worksheet (serial 200522R2-4, program line MB1000 P183) with target equipment Zeiss Sigma 300 for Baosteel Zhanjiang. Operator Munho Noh (Daeil System, research engineer); setup and reporting on 2020.09.11; measurement the same calendar day at zhanjiang with the Overview text and fixed-frequency transmissibility table copied from the DOCX; MB1000 internal-program screenshots under Z axis, X axis, and Y axis follow §2a embed mapping (image2–4). Decorative bitmap on the centred “MB1000_200522R2-4(P183) Set up” title line is not republished. The sheet has no Vibration specification, Reference, or Measurement Summary headings beyond “Summary of measurement results”; none were added.

DVIA-MB1000 serial 200522R7 (project P163) for Zeiss Evo 18 reported by /channel partner; installation table lists SHANDONG and end user 山东蓝翔 while the measurement block lists Place of measurement: Shangdong. Figures follow Z axis, X axis, and Y axis per Word; the raster under the title line after `(MB1000_200522R7(P163) Set up)` is not republished.

UB1000 project P10 (series 190916R10): remote tuning worksheet for Zeiss SUPRA 25 at Foshan, END USER Fozhixin. Section order follows the Word file: centred Set up title, installation photograph next (DOCX §2a: rId8 → image1.jpeg), then target/end-user/date tables and overview text; UB1000 internal-program Z/X/Y captures follow matching **Z/X/Y axis** headings. Measurement date 2020-09-10; transmissibility summary reproduced as printed; no standalone Reference appendix in source.

DVIA-MB1000 worksheet P173, isolator serial 191219R3-4, for Hitachi HT7800. Remote tuning handout dated setup 2020-09-02 and reporting 2020-09-03 (operator Choi, HyoungMun, Daeil System). The DOCX title line reads MB1000_P173; the VC-Class summary table cells are empty in the source as issued; Z / X / Y captions are followed by MB1000 internal-program screenshots uploaded as figure_01–03. The raster under the centred Set up title is decorative and is not republished.

DVIA-MB1000 worksheet P175 (isolator serial 191219R3-5) for a Hitachi HT7800 under Nemo remote tuning: setup on 2020-09-02 and reporting on 2020-09-03 (operator Choi, HyoungMun, Daeil System). The VC-Class summary table matches the source with blank numeric cells, followed by the Good omnidirectional performance line and MB1000 internal-program captures for Z, X, and Y per §2a embed mapping. The raster under the centred title block is not republished.

DVIA-MB1000 serial 191211R4 (project P154) remote tuning handout dated 2020.08.28 for Thermo Scientific Scios 2 installed at Beijing Software Testing & QA Center for National Application Software Testing Labs. Published items follow Word order after the structured setup block; the JPEG under the `(MB1000_191211R4(P154) Set up)` banner is treated as decorative and excluded.
