Vibration Isolation Case Studies

DVIA-M1000 installation report (serial 241101R9) — Ciqtek High Speed SEM HEM6000. Field package. UI-program transmissibility plots and equipment photo; Reference as markdown VC table.

DVIA-M-THT3 serial 240807R5 — handout for Xiamen Street Lighting Institute, target equipment Thermo Fisher Scientific Talos, installation Xiamen. Overview and measurement metadata match the published form; M-THT3 internal program performance plots labeled Vertical, Left to Right, and Front to Back from the UI program. Cover-only header graphics are not republished.

DVIA-M1000 (serial 171009R1 on the issued form; Word filename revision 171009R2) tuning and vibration measurement at Seohan Technology Research Institute — 3F materials testing lab. JEOL SEM JSM-IT500 with Data Physics QUATTRO and PCB 393B05. Nine-axis VC / Autospectrum / Transmissibility plots plus an equipment photograph; opening JEOL tagline raster and the appendix reference raster are not republished — ISO/VC criteria appear as the site markdown table.

DVIA-M1000 abbreviated worksheet (serial 230706R2; intake filename M1000_2307060R2_24.08.19.docx — body spells 230706R2). Setup dated 24.08.19 and reporting dated 24.12.04; measurement date 2024.08.19 (Monday) in Shanghai with operator Chaewon Lee from DAEIL SYSTEMS. END USER Donghua University; target equipment HITACHI SU7000 and place of installation Shanghai as in the form. The Overview block states the standard DVIA-M1000 sentence only. No vibration specification, equipment status, tuning request, measurement summary table, or Reference section appears in the source. The internal-program section title in the source reads “M1000 internal program performance measurement result”; published figures are three plots labeled Vertical, Left to Right, and Front to Back. Decorative header graphics from the Word file are omitted from public copy.

DVIA-M1000 installation report (serial 231009R3) for ZEISS Sigma300 SEM at Xi’an Jiaotong University. Internal M1000 program performance plots: vertical, left-to-right, and front-to-back transmissibility with coherence; equipment installation photo; site summary and overview from the issued form. Reference uses the standard Generic Vibration Criteria markdown table only.

DVIA-M1000 installation report (serial 240827R2) for ZEISS FE-SEM Sigma360. Overview matches the published form. Equipment condition: The equipment is installed/Turned off. Published figures include UI-program plots as listed; Reference uses the standard Generic Vibration Criteria markdown table.
