Vibration Isolation Case Studies

DVIA-MB1000 installation report (serial 240314R3) for ZEISS Sigma 360, Xi'an, China.

DVIA-M1000 installation report — ZEISS FIB-SEM Crossbeam 550 (serial 240314R6) for BYD Semiconductor in Chengdu, China. Overview states the platform is appropriately installed and functioning as intended. The published form has no separate vibration specification section or measurement summary table. Equipment condition: The equipment is installed. Tuning request as UI-program capture; vertical, left-to-right, and front-to-back transmissibility; on-site equipment photo; Reference uses the standard Generic Vibration Criteria markdown table.

DVIA-MB1000 installation report (serial 240327R3) for ZEISS GeminiSEM 360. Prepared for field is not filled (N/A); location N / A on the form.

DVIA-M1000 installation report — ZEISS FIB-SEM Crossbeam 350 (serial 240409R2) for Shenghe Jingwei in Jiangyin, China. Overview states the platform is appropriately installed and functioning as intended. The published form has no separate vibration specification section or measurement summary table. Equipment condition: The equipment is installed/IDLE. Tuning request as UI-program capture; vertical, left-to-right, and front-to-back transmissibility; on-site equipment photo; Reference uses the standard Generic Vibration Criteria markdown table.

DVIA-M1000 installation report — QIYUE TECHNOLOGY In situ SEM 660F (serial 240411R7), channel. Overview states the platform is appropriately installed and functioning as intended. The published handout has no vibration specification section and no measurement summary table. Prepared for, location, and end user are blank on the form (N/A). Equipment condition: The equipment is installed/Turned off. Tuning request is blank (N/A). Published figures: UI-program Transmissibility (vertical, left to right, front to back) and on-site equipment photo under section 11; Reference uses the standard Generic Vibration Criteria markdown table (no separate reference graphic).

DVIA-M1000 installation report — ZEISS FIB-SEM Crossbeam 550 (serial 240417R5), field package. Overview states the platform is appropriately installed and functioning as intended. End user and installation location are not filled on the published form (N/A). Equipment condition: The equipment is installed. Published figures: UI-program Transmissibility (vertical, left-to-right, front-to-back) and on-site equipment photo; Reference uses the standard Generic Vibration Criteria markdown table (no separate reference graphic). The published handout has no Tuning Request section or separate vibration specification section.
