Vibration Isolation Case Studies

CSOT Wuhan — HELIOS 5 UC on DVIA-M1000 (SN 220401R2). MB1000 internal program plots and octave-band results.

DVIA-UB350 (S/N 220727R3) installation report for SNU Precision headquarters (Asan): first setup noise from stage motion resolved by replacing 70 kg springs with 180 kg springs, followed by second setup and vibration measurement 2022-09-21. Published VC-curve and transmissibility plots (before/after adjustment) for Z/X/Y axes, spring-replacement summary tables, and PULSE 22 measurement setup notes; decorative title-block bitmap (image1) and Generic Vibration Criteria figure (image17) omitted — Reference uses the site VC criterion markdown table.

DVIA-M1000 worksheet for serial 220718R3 (source M1000_220718R3_22.09.19.docx). END USER Jiangsu Modern Road & Bridge · Axia ChemiSEM HiVac in Nanjing. Setup/reporting dated 22.09.19 per the form with operator Yu, Ho Sang; measurement session 2022.09.19 (Monday) recorded as printed. Publication includes installation photograph under the setup title row, VC-Class Floor vs Above Active summary, MB1000 internal-program transmissibility/coherence screenshots, and octave-band spectra. Decorative signature-block raster on the company-header line was omitted.

DVIA-UB1000 (serial 180305R3, 1140×910×224H mm) installation report at Tier-1 Semiconductor, icheon-si for Hitachi FE SEM equipment — tuned 2022-09-07 by Seounghoon Cheon (DAEIL SYSTEMS), reported 2022-09-14. Measurement with Data Physics Quattro / SignalCalc ACE; FFT 0–80 Hz, Hanning / 800 lines. VC summary (equipment off): Floor vs Active across Z/X/Y bands as in the Measurement Summary table. Publishes equipment-off Floor / Top VC and Transmissibility plots (nine figures). Decorative cover header bitmap omitted; ISO/VC reference chart replaced with markdown table.

DVIA-UB700 (S/N 220209R02) installation report prepared for New National Metrology Centre; GBI system/600 kg at 2 Fusionopolis Way, Singapore; engineer Seounghoon Cheon. Tuning date 22.09.06 and report written date 22.09.14 per worksheet. Publication includes Data and Image: Z/X/Y-axis transmissibility plots; decorative header bitmap (image1) and Reference VC-criteria raster (image5) omitted.

DVIA-UB350 (1260×800, serial 220211R02) horizontal-isolation performance check and retuning at Tier-1 Display Manufacturer (Paju) M2 for SNU CTQ equipment (2022-09-08 tuning, report 2022-09-14; engineers Cheon Seunghoon and Youngha Lee). Passive level adjusted for stage position and gain increased; six VC curves and transmissibility plots with 5 Hz / 10 Hz attenuation notes. Summary VC-class table; Reference as markdown criteria only.
